U6268B
Rev. A3, 11-Apr-01
6 (13)
In case of a detected overtemperature, only the corre-
sponding channel is disabled. The other channel stays
enabled.
The RETURNx is switched off if the voltage at RE-
TURNx is higher than 2 V (short-circuit comparator
threshold) and overtemperature is detected.
The OUTx is switched off if the voltage at OCMx is
higher than 4.6 V (overcurrent detection level) and over-
temperature is detected. The OCM voltage monitors the
output current at OUTx via the current ratio of 0.1. The
overcurrent-detection level of OUTx can be varied by
changing the OCMx resistor. If OUTx is switched off by
overtemperature and overcurrent detection, the CLLx
output remains logic low (overcurrent).
As the IC is only overtemperature-protected for short-cir-
cuit conditions at RETURNx or OUTx, it has to be
checked in each application that the chip temperature
does not exceed T
jmax
= 150
°
C in normal operation.
Test Hint
The overtemperature signal can be activated by connect-
ing ENABLE1 or ENABLE2 to 9 V/ 10 mA.
Absolute Maximum Ratings
Parameters
Symbol
V
S
Min.
–0.6
–0.3
–0.3
–0.3
–1
–1
Typ.
Max.
40
6
30
6.8
27
40
240
Unit
V
V
V
V
V
V
mA
Supply voltage
Voltage at pins CLL1, CLL2, ENABLE1, ENABLE2
Voltage at SC
Voltage at OCM1, OCM2
Voltage at RETURN1, RETURN2
Voltage at OUT1, OUT2
Current at supply
(both channels OUTx and RETURNx shorted)
Current at logical pins: CLL1, CLL2
ENABLE1, ENABLE2
Current at SC (SC related to GND or V
Batt
)
Current at pins to external unit
OUT1, OUT2, RETURN1, RETURN2
ESD classification
Human body model (100 pF, 1.5 k )
Machine model (200 pF, 0.0 )
Ambient temperature range
Junction temperature range
Storage temperature range
V
SC
V
OCMx
V
RETURNx
V
OUTx
I
S
I
CCLx
I
ENABLEx
I
SC
3
0.1
220
mA
mA
A
–110
internal
limited
All pins
2000
200
–40
–40
–55
V
V
°
C
°
C
°
C
T
amb
T
j
T
stg
95
150
125
Thermal Resistance
Parameters
Symbol
R
thJC
Value
36
Unit
K/W
Junction case
Note:
A good thermal resistance junction ambient (R
thJA
= 65 K/W) can be achieved by using a big pad size for ground con-
nection nearby a metal component (see description of GND-pins).
