General Specifications
General Specifications
Data
Ambient temperature
0 – 55 °C
Operating temperature
0 – 55 °C
Storage temperature
-20 – +70 °C
Primary power supply
24 V DC,200 mA; ripple ratio at maximum load:
≤±5%
Protection
IP 20
Noise durability
1000 Vpp with noise generator;1
sat 30–100Hz
Dielectric withstand voltage
1500 V AC,1 min.(500 V AC for direct voltage modules)
Ambient relative humidity
35 – 85 % (non-condensing)
Shock resistance
10 G (3 times each in 3 directions)
Vibration resistance
2 G:resistance to vibrations from 10 – 55 Hz for 2 hours along all 3 axes;0.5 G for DIN rail mounting
Insulation resistance
500 V DC,5 M
Ground
Class 3
Fuse
3 A
Environment
Avoid environments containing corrosive gases,install in a dust-free location.
Certifications
UL / CSA / CE / DNV / RINA
Specifications
FX0S-10
MR-DS
FX0S-10
MR-ES/UL
FX0S-10
MT-DSS
FX0S-14
MR-DS
FX0S-14
MR-ES/UL
FX0S-14
MT-DSS
Elektrical data
Max. number inputs/outputs
10
14
Power
supply
AC range (+10%, -15%)
—
100–240 V AC
—
100–240 V AC
—
Frequency at AC
Hz —
50/60 (
±10%)
—
50/60 (
±10%)
—
DC range (+10%, -15%)
24 V DC
—
24 V DC
—
24 V DC
Max. input apparent power
4W
30VA
4W
5W
30 VA
5W
Inrush
current
at ON
100 V AC
—15 A / 2 ms
——15 A / 2 ms
—
200 V AC
—25 A / 2 ms
——25 A / 2 ms
—
24 V DC
60 A / 1.5 ms
—
60 A / 1.5 ms
—
60 A / 1.5 ms
Allowable momentary power failure time
ms 5
10
5
10
5
External current supply (24 V DC)
mA —
200
—
200
—
Inputs
Integrated inputs
66
6888
Min. current for logical 1
mA 4.5
4.5
Max. current for logical 0
mA 1.5
1.5
Response time
ms For all units of the MELSEC FX0S series values:10 ms (at time of shipping),adjustable from 0 to 15 ms in steps of 1 ms.
Outputs
Integrated outputs
4
4666
Output
Art Relay
Relay
Transistor
Relay
Transistor
Switching voltage (max.)
V Generally for relay version:< 264 V AC,< 30 V DC;for transistor version:5 – 30 V DC
Max. output
current
- per output
A 2.5
2.5
0.5
2.5
0.5
- per group*
A —
—
0.8
8
0.8
Max. switching
current
- inductive load
80 VA
80VA
12W
80VA
80 VA
12 W
- lamp load
W 100
100
1.5
100
1.5
Response time
ms 10
10
0.2
10
0.2
Life of contacts (switching times)
For all base units of the MELSEC FX0S series values:3000000 at 20 VA;1000000 at 35 VA;200000 at 80 VA
Mechanical data
Weight
kg 0.3
0.45
0.3
0.45
0.3
Dimensions (W x H x D)
mm 60 x 90 x 47
60 x 90 x 75
60 x 90 x 47
60 x 90 x 75
60 x 90 x 47
Order information
Art. no. 55774
55773
55775
55777
55776
55778
* The limitation applies only per reference terminal for each group,4 and 8 outputs for relays and 2 and 4 outputs for transistors.Please observe the terminal assignments for the group identification.
Specifications of Base Units
MELSEC FX0S
BASE UNITS
Specifications
BASICS
X
FX
F
MITSUBISHI ELECTRIC
