MRF21180 MRF21180S
4
MOTOROLA RF DEVICE DATA
Figure 1. MRF21180 Test Circuit Schematic
RF
INPUT
RF
OUTPUT
Z9
VGG
R5
R1
B1
R3
C5
C11
C15
C23
+
C1
C2
Z7
Z5
Z3
Z8
Z6
Z4
Z1
Z2
Z10
VGG
R2
B2
R4
C6
C12
C16
C24
+
DUT
VDD
C4
Z17
Z15
Z11
Z13
Z20
Z19
C9
C8
C18
C14
C19
+
C21
+
C3
Z18
Z16
Z12
Z14
VDD
C10
C7
C17
C13
C20
+
C22
+
Table 1. MRF21180 Test Circuit Component Designations and Values
Part
Description
Value, P/N or DWG
Manufacturer
B1, B2
Short Ferrite Beads
2743019447
Fair Rite
C1, C2, C3, C4
30 pF Chip Capacitors
100B300JCA500X
ATC
C5, C6, C7, C8
5.6 pF Chip Capacitors
100B5R6JCA500X
ATC
C9, C10
10
F Tantalum Capacitors
T495X106K035AS4394
Kemet
C11, C12, C13, C14
1000 pF Chip Capacitors
100B102JCA500X
ATC
C15, C16, C17, C18
0.1
F Chip Capacitors
CDR33BX104AKWS
Kemet
C19, C20
1.0
F Tantalum Capacitors
T491C105M050
Kemet
C21, C22, C23, C24
22
F Tantalum Capacitors
T491X226K035AS4394
Kemet
N1, N2
Type N Flange Mounts
3052-1648-10
Omni Spectra
R1, R2, R3, R4
10
, 1/8 W Chip Resistors
R5
1.0 k
, 1/8 W Chip Resistor
Z1, Z20
Microstrip
0.790
″ x 0.065″
Z2, Z19
Microstrip
0.830
″ x 0.112″
Z3, Z18
Microstrip
0.145
″ x 0.065″
Z4, Z17
Microstrip
1.700
″ x 0.065″
Z5, Z6
Microstrip
0.340
″ x 0.065″
Z7, Z8
Microstrip
0.455
″ x 0.600″
Z9, Z10
Microstrip
0.980
″ x 0.035″
Z11, Z12
Microstrip
0.510
″ x 0.645″
Z13, Z14
Microstrip
0.770
″ x 0.058″
Z15, Z16
Microstrip
0.280
″ x 0.065″
WB1, WB2, WB3, WB4
Wear Blocks
Board
0.030
″ Glass Teflon
RF-35,
εr = 3.50
Taconic
PCB
Etched Circuit Boards
MRF21180 Rev. 4
CMR
