5-82
Freescale Semiconductor
Wireless RF Product Device Data
MRF377 MRF377R3 MRF377R5
6.57 - j4.03
660
Figure 19. 470—860 MHz Broadband Series Equivalent Source and Load Impedance
f
MHz
Zsource
Zload
470
560
5.79 - j2.40
6.63 - j2.63
6.21 - j1.69
5.66 - j1.12
6.76 - j1.00
Optimized for VDD = 32 V, IDQ = 2 x 1000 mA, Pout = 45 W Avg., DVBT OFDM
Zsource = Test circuit impedance as measured from
gate to gate, balanced configuration.
Zload
= Test circuit impedance as measured
from drain to drain, balanced configuration.
Zsource
Z load
Input
Matching
Network
Device
Under
Test
Output
Matching
Network
+
Zo = 10
f = 470 MHz
f = 860 MHz
f = 470 MHz
Zload
Zsource
760
860
5.34 - j6.28
6.67 - j4.55
6.57 - j1.91
7.37 - j5.45
Zo = 10
