5-78
Freescale Semiconductor
Wireless RF Product Device Data
MRF377 MRF377R3 MRF377R5
Table 6. 470—860 MHz Broadband Test Circuit Component Designations and Values
Part
Description
Part Number
Manufacturer
B1, B2
Ferrite Beads, Surface Mount, 30 (0603)
2506033007Y0
Fair-Rite
Balun 1, Balun 2
Rogers 3.006, εr = 6.06, 1 oz Cu
DS1046
DS Electronics
C1
12 pF Chip Capacitor (0603)
06035J120GBT
AVX / Kyocera
C2, C5
12 pF Chip Capacitors (0805)
08051J120GBT
AVX / Kyocera
C3
3.9 pF Chip Capacitor (0805)
08051J3R9BBT
AVX / Kyocera
C4, C7, C12, C15, C17
8.2 pF Chip Capacitors (0805)
08051J8R2BBT
AVX / Kyocera
C6
3.3 pF Chip Capacitor (0805)
08051J3R3BBT
AVX / Kyocera
C8
0.4-2.5 pF Variable Capacitor
27283PC
Gigatronics
C9, C10
3.3 pF Chip Capacitors (0603)
06035J3R3BBT
AVX / Kyocera
C11, C14
10 pF Chip Capacitor (0805)
08051J100GBT
AVX / Kyocera
C13
4.7 pF Chip Capacitor (0805)
08051J4R7BBT
AVX / Kyocera
C16
2.2 pF Chip Capacitor (0603)
06035J2R2BBT
AVX / Kyocera
C18
2.2 pF Chip Capacitor (0805)
08051J2R2BBT
AVX / Kyocera
C19, C20, C21, C22
47 F, 16 V Tantalum Chip Capacitors
TPSD476K016R0150
AVX
C23, C26
2.2 F, 50 V Ceramic Chip Capacitors
C1825C225J5RAC3810
Kemet
C24, C25, C27, C29
0.01 F, 100 V Ceramic Chip Capacitors
C1825C103J1GAC
Kemet
C28, C30
0.56 F, 50 V Ceramic Chip Capacitors
C1825C564J5GAC
Kemet
C31, C32
10 F, 50 V Chip Capacitors
522Z-050/100MTRE
Tecate
C33, C34
470 F, 63 V Electrolytic Capacitors
SME63VB471M12X25LL
United Chemi-Con
L1, L2
15 nH Inductors (0603)
L0603150GGW003
AVX
L3, L4
12 nH Inductors (0603)
0603HC-12NHJBU
CoilCraft
L5, L6
8 nH Coil Inductors
A03T-5
CoilCraft
L7
22 nH Coil Inductor
B07T-5
CoilCraft
L8
18.5 nH Coil Inductor
A05T-5
CoilCraft
R1, R2
12.1 , 1/16 W, 1% Chip Resistors (0603)
PCB Gate, PCB Drain
PCB Motherboard w/Integrated Daughterboard,
Rogers 3003, εr = 3.03, 0.5 oz Cu
DS1047
DS Electronics
