Philips Semiconductors
Preliminary data
P87LPC760
Low power, low price, low pin count (14 pin)
microcontroller with 1 kbyte OTP
2002 Mar 07
27
Timer/Counters
The P87LPC760 has two general purpose counter/timers which are
upward compatible with the standard 80C51 Timer 0 and Timer 1.
Both can be configured to operate as timers or can be configured to
be an event counter (see Figure 22). An option to automatically
toggle the T0 pin upon timer overflow has been added.
In the “Timer” function, the register is incremented every machine
cycle. Thus, one can think of it as counting machine cycles. Since a
machine cycle consists of 6 CPU clock periods, the count rate is 1/6
of the CPU clock frequency. Refer to the section Enhanced CPU for
a description of the CPU clock.
In the “Counter” function of Timer 0, the register is incremented in
response to a 1-to-0 transition at its corresponding external input
pin, T0. In this function, the external input is sampled once during
every machine cycle. When the samples of the pin state show a
high in one cycle and a low in the next cycle, the count is
incremented. The new count value appears in the register during the
cycle following the one in which the transition was detected. Since it
takes 2 machine cycles (12 CPU clocks) to recognize a 1-to-0
transition, the maximum count rate is 1/6 of the CPU clock
frequency. There are no restrictions on the duty cycle of the external
input signal, but to ensure that a given level is sampled at least once
before it changes, it should be held for at least one full machine
cycle.
The “Timer” or “Counter” function of Timer 0 is selected by control bit
C/T in the Special Function Register TMOD. In addition to the
“Timer” or “Counter” selection, Timer 0 and Timer 1 have four
operating modes, which are selected by bit-pairs (M1, M0) in TMOD.
Modes 0, 1, and 2 are the same for both Timers/Counters. Mode 3 is
different. The four operating modes are described in the following
text.
BIT
TMOD.7, 6
TMOD.5, 4
TMOD.3
SYMBOL
–
M1, M0
GATE
FUNCTION
Reserved. Must be written with zeros only.
Mode Select for Timer 1 (see table below).
Gating control for Timer 0. When set, Timer/Counter is enabled only while the INT0 pin is high and
the TR0 control pin is set. When cleared, Timer 0 is enabled when the TR0 control bit is set.
Timer or Counter Selector for Timer 0. Cleared for Timer operation (input from internal system clock.)
Set for Counter operation (input from T0 input pin).
Mode Select for Timer 0 (see table below).
Timer Mode
8048 Timer “TLn” serves as 5-bit prescaler.
16-bit Timer/Counter “THn” and “TLn” are cascaded; there is no prescaler.
8-bit auto-reload Timer/Counter. THn holds a value which is loaded into TLn when it overflows.
Timer 0 is a dual 8-bit Timer/Counter in this mode. TL0 is an 8-bit Timer/Counter controlled by the
standard Timer 0 control bits. TH0 is an 8-bit timer only, controlled by the Timer 1 control bits (see
text). Timer 1 in this mode is stopped.
TMOD.2
C/T
TMOD.1, 0
M1, M0
M1, M0
0 0
0 1
1 0
1 1
M0
SU01542
M1
C/T
GATE
M0
M1
–
–
0
1
2
3
4
5
6
7
TMOD
Reset Value: 00h
Not Bit Addressable
Address: 89h
T1
T0
Figure 22. Timer/Counter Mode Control Register (TMOD)
