SLAS506B – NOVEMBER 2006 – REVISED DECEMBER 2008........................................................................................................................................ www.ti.com
Page 1 / Register 7:
Left Channel Audio Effects Filter N3 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01101011
Left Channel Audio Effects Filter N3 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s
complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 8:
Left Channel Audio Effects Filter N3 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
11100011
Left Channel Audio Effects Filter N3 Coefficient LSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s
complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 9:
Left Channel Audio Effects Filter N4 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
10010110
Left Channel Audio Effects Filter N4 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 10:
Left Channel Audio Effects Filter N4 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01100110
Left Channel Audio Effects Filter N4 Coefficient LSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s
complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 11:
Left Channel Audio Effects Filter N5 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01100111
Left Channel Audio Effects Filter N5 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 12:
Left Channel Audio Effects Filter N5 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01011101
D7-D0 R/W 00000000 Left Channel Audio Effects Filter N5 Coefficient LSB The 16-bit integer
contained in the MSB and LSB registers for this coefficient are interpreted as a 2’s complement
integer, with possible values ranging from -32768 to +32767.
Page 1 / Register 13:
Left Channel Audio Effects Filter D1 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01111101
Left Channel Audio Effects Filter D1 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 14:
Left Channel Audio Effects Filter D1 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
10000011
Left Channel Audio Effects Filter D1 Coefficient LSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
56
Copyright 2006–2008, Texas Instruments Incorporated
Product Folder Link(s): TLV320DAC32
