www.ti.com........................................................................................................................................ SLAS506B – NOVEMBER 2006 – REVISED DECEMBER 2008
Page 1 / Register 15:
Left Channel Audio Effects Filter D2 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
10000100
Left Channel Audio Effects Filter D2 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 16:
Left Channel Audio Effects Filter D2 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
11101110
Left Channel Audio Effects Filter D2 Coefficient LSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 17:
Left Channel Audio Effects Filter D4 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01111101
Left Channel Audio Effects Filter D4 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 18:
Left Channel Audio Effects Filter D4 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
10000011
Left Channel Audio Effects Filter D4 Coefficient LSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 19:
Left Channel Audio Effects Filter D5 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
10000100
Left Channel Audio Effects Filter D5 Coefficient MSB
The 16-bit integer contained in the MSB and LSB registers for this coefficient are interpreted as a
2’s complement integer, with possible values ranging from –32768 to +32767.
Page 1 / Register 20:
Left Channel Audio Effects Filter D5 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
11101110
Left Channel Audio Effects Filter D5 Coefficient LSB The 16-bit integer contained in the MSB and
LSB registers for this coefficient are interpreted as a 2’s complement integer, with possible values
ranging from –32768 to +32767.
Page 1 / Register 21:
Left Channel De-emphasis Filter N0 Coefficient MSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
00111001
Left Channel De-emphasis Filter N0 Coefficient MSB The 16-bit integer contained in the MSB and
LSB registers for this coefficient are interpreted as a 2’s complement integer, with possible values
ranging from –32768 to +32767.
Page 1 / Register 22:
Left Channel De-emphasis Filter N0 Coefficient LSB Register
BIT
READ/
RESET
DESCRIPTION
WRITE
VALUE
D7-D0
R/W
01010101
Left Channel De-emphasis Filter N0 Coefficient LSB The 16-bit integer contained in the MSB and
LSB registers for this coefficient are interpreted as a 2’s complement integer, with possible values
ranging from –32768 to +32767.
Copyright 2006–2008, Texas Instruments Incorporated
57
Product Folder Link(s): TLV320DAC32
