2002 Oct 30
3
Philips Semiconductors
Objective specification
Wideband code division multiple access
frequency division duplex zero IF receiver
UAA3580
1
FEATURES
Low noise wide dynamic range for zero IF receivers
79 dB gain control range; in steps of 1 dB
Channel filters
96 dB voltage gain
Fully integrated fractional-N synthesizer with AFC
control capability
Fully integrated RF VCO with integrated supply voltage
regulator
Fully differential design to minimize crosstalk
Supply voltage from 2.4 to 3.3 V
3-wire serial interface bus
HVQFN24 package.
2
APPLICATIONS
WCDM-FDD receiver for GSM hand-portable equipment
Dual mode GSM/GPRS/EDGE/UMTS handset.
3
GENERAL DESCRIPTION
The UAA3580 is a BiCMOS integrated circuit receiver
intended for the Third Generation Partnership Project
(3GPP) specification for the Universal Mobile
Telecommunication System (UMTS).
ThecircuitisspeciallydesignedfortheFrequencyDivision
Duplex (FDD) mode of the Wide Code Division Multiple
Access (WCDMA) that operates in the 2110 to 2170 MHz
band.
The UAA3580 contains the whole analog receive chain
from Radio Frequency (RF) Low Noise Amplifier (LNA) to
baseband IQ outputs including a channel filter, a complete
RF Phase-Locked Loop (PLL) with a fully integrated
Voltage Controlled Oscillator (VCO), and a clock PLL that
generates a programmable UMTS system clock from an
external 26 MHz reference signal.
4
QUICK REFERENCE DATA
5
ORDERING INFORMATION
SYMBOL
PARAMETER
MIN.
TYP.
MAX.
UNIT
V
CCA
V
DDD
T
amb
analog supply voltage
digital supply voltage
ambient temperature
2.6
1.6
30
3.3
2.8
+70
V
V
°
C
TYPE
NUMBER
PACKAGE
VERSION
NAME
DESCRIPTION
UAA3580HN
HVQFN24
plastic, heatsink very thin quad flat package; no leads
24 terminals; body 4
×
4
×
0.90 mm
SOT616-1
