1999 Aug 10
13
Philips Semiconductors
Preliminary specification
Full bridge driver IC
UBA2030T
Application with external control
Figure 5 shows an application containing an external
oscillator control circuit referenced to system ground.
The RC, BER and BE pins are connected to system
ground. The bridge commutation frequency is determined
by the external oscillator. The shut-down input (pin SD)
can be used to quickly turn off all four MOSFETs in the full
bridge.
Fig.5 External control configuration.
handbook, full pagewidth
UBA2030T
SHR
GHR
FSR
VDD
SGND
HV
EXO
SD
DTC
SHL
GHL
FSL
PGND
GLR
BER
BE
RC
GLL
13
14
15
18
20
21
22
23
24
12
11
10
8
7
5
3
2
1
IGNITOR
LAMP
Ci
C3
RDT
C2
C4
C1
LL
HL
C5
LR
HR
system
ground
MGK593
EXTERNAL
OSCILLATOR
CONTROL
CIRCUIT
