AD9851
–4–
REV. 0
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD9851 features proprietary ESD protection circuitry, permanent damage may
occur on devices subjected to high energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
ABSOLUTE MAXIMUM RATINGS*
Maximum Junction Temperature . . . . . . . . . . . . . . . .+150
°
C
Storage Temperature . . . . . . . . . . . . . . . . . . –65
°
C to +150
°
C
V
S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +6 V
Operating Temperature . . . . . . . . . . . . . . . . . –40
°
C to +85
°
C
Digital Inputs . . . . . . . . . . . . . . . . . . . –0.7 V to +V
S
+ 0.7 V
Lead Temperature (10 sec) Soldering . . . . . . . . . . . . .+300
°
C
Digital Output Current . . . . . . . . . . . . . . . . . . . . . . . . 30 mA
SSOP
θ
JA
Thermal Impedance . . . . . . . . . . . . . . . . . . 82
°
C/W
DAC Output Current . . . . . . . . . . . . . . . . . . . . . . . . . .30 mA
*Absolute maximum ratings are limiting values, to be applied individually, and
beyond which the serviceability of the circuit may be impaired. Functional
operability under any of these conditions is not necessarily implied. Exposure of
absolute maximum rating conditions for extended periods of time may affect
device reliability.
EXPLANATION OF TEST LEVELS
Test Level
I
– 100% Production Tested.
III – Sample Tested Only.
IV
– Parameter is guaranteed by design and characterization
testing.
V
– Parameter is a typical value only.
VI
– Devices are 100% production tested at +25
°
C and
guaranteed by design and characterization testing for
industrial operating temperature range.
ORDERING GUIDE
Model
Temperature Range
Package Description
Package Option
AD9851BRS
–40
°
C to +85
°
C
Shrink Small Outline (SSOP)
RS-28
