REV. A
AD9882
–9–
PIN DESCRIPTIONS OF SHARED PINS BETWEEN
ANALOG AND DIGITAL INTERFACES
HSOUT
Horizontal Sync Output
A reconstructed and phase-aligned version of the
video Hsync. The polarity of this output can be
controlled via a serial bus bit. In analog interface
mode, the placement and duration are variable.
In digital interface mode, the placement and
duration are set by the graphics transmitter.
VSOUT
Vertical Sync Output
The separated Vsync from a composite signal or
a direct pass-through of the Vsync input. The
polarity of this output can be controlled via a
serial bus bit. The placement and duration in all
modes is set by the graphics transmitter.
SERIAL PORT (2-WIRE)
SDA
SCL
A0
Serial Port Data I/O
Serial Port Data Clock
Serial Port Address Input
For a full description of the 2-wire serial register,
refer to the Control Port section on 2-Wire
Serial Control.
DATA OUTPUTS
RED
GREEN
BLUE
Data Output, RED Channel
Data Output, GREEN Channel
Data Output, BLUE Channel
The main data outputs. Bit 7 is the MSB. These
outputs are shared between the two interfaces
and behave according to which interface is active.
Refer to the sections on the two interfaces for
more information on how these outputs behave.
Data Output Clock
Just like the data outputs, the data clock output
is shared between the two interfaces. It behaves
differently depending on which interface is active.
Refer to the sections on the two interfaces to
determine how this pin behaves.
DATACK
Table II. Analog Interface Pin List
Pin
Number
Pin Type
Mnemonic
Function
Value
Analog Video
Inputs
R
AIN
G
AIN
B
AIN
HSYNC
VSYNC
SOGIN
Analog Input for Converter R
Analog Input for Converter G
Analog Input for Converter B
0.0 V to 1.0 V
0.0 V to 1.0 V
0.0 V to 1.0 V
70
65
59
External
Sync/Clock
Horizontal SYNC Input
Vertical SYNC Input
Sync-on-Green Input
3.3 V CMOS
3.3 V CMOS
0.0 V to 1.0 V
79
80
64
Sync Outputs
HSOUT
VSOUT
SOGOUT
Hsync Output (Phase-Aligned with DATACK)
Vsync Output
Composite SYNC
3.3 V CMOS
3.3 V CMOS
3.3 V CMOS
88
87
89
Voltage
Reference
Clamp Voltages
REFBYPASS
MIDBYPASS
Internal Reference Bypass
Internal Midscale Voltage Bypass
1.25 V
73
74
PLL Filter
FILT
Connection for External Filter Components for Internal PLL
48
Power Supply
V
D
PV
D
V
DD
GND
Main Power Supply
PLL Power Supply (Nominally 3.3 V)
Output Power Supply
Ground
3.15 V to 3.45 V
3.15 V to 3.45 V
2.2 V to 3.6 V
0 V
