ISP1501
Hi-Speed Universal Serial Bus peripheral transceiver
Rev. 02 — 21 November 2002
Product data
1.
General description
The ISP1501 is a full-function transceiver designed to provide a Hi-Speed Universal
Serial Bus (USB) analog front-end to Application-Specific Integrated Circuits (ASICs)
and Field Programmable Gate Arrays (FPGAs) with a built-in USB Serial Interface
Engine (SIE). A Hi-Speed USB transceiver is integrated to implement USB
connectivity for high-speed peripherals. In addition, an Original USB transceiver
provides backward compatibility with full-speed USB systems. A minimum number of
external components is needed.
2.
Features
I
Complies with Universal Serial Bus Specification Rev. 2.0
I
Legacy compliant Original USB full-speed transceiver interface
I
Bus-powered capability with suspend mode
I
Integrated parallel-to-serial converter (transmit) and serial-to-parallel converter
(receive) for Hi-Speed USB data
I
Hi-Speed USB data recovery upon receiving
I
Hi-Speed USB data synchronization upon transmitting
I
Integrated bit stuffing and de-stuffing for Hi-Speed USB data
I
Non-Return-to-Zero Inverted (NRZI) encoding and decoding for Hi-Speed
USB data
I
Integrated Phase Locked Loop (PLL) oscillator using 12 MHz crystal
I
Internal power-on reset
I
Separate 3.3 V supplies for analog transceiver and digital I/Os minimizes
crosstalk
I
3.3 V or 5 V tolerant digital input interface
I
16-bit bi-directional data bus allows FPGA verification, greatly reducing ASIC
implementation risk
I
Full industrial operating temperature range from
40 to
+
85
°
C
I
6 kV in-circuit ESD protection; compliant with IEC 61000-4-2(level 3)
I
Available in LQFP48 package.
