SLAS548C
– OCTOBER 2008 – REVISED APRIL 2011
Control Registers, Page 4: ADC Digital Filter Coefficients
Default values shown for this page only become valid 100
μs following a hardware or software reset.
Page 4 / Register 0: Page Control Register(1)
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
–D0
R/W
0000 0000
0000 0000: Page 0 selected
0000 0001: Page 1 selected
...
1111 1110: Page 254 selected (reserved)
1111 1111: Page 255 selected (reserved)
(1)
Valid pages are 0, 1, 4, 5, 32
–47. All other pages are reserved (do not access).
The remaining page-4 registers are either reserved registers or are used for setting coefficients for the various
filters in the processing blocks. Reserved registers should not be written to.
The filter coefficient registers are arranged in pairs, with two adjacent 8-bit registers containing the 16-bit
coefficient for a single filter. The 16-bit integer contained in the MSB and LSB registers for a coefficient are
interpreted as a 2s-complement integer, with possible values ranging from
–32,768 to 32,767. When
programming any coefficient value for a filter, the MSB register should always be written first, immediately
followed by the LSB register. Even if only the MSB or LSB portion of the coefficient changes, both registers
should be written in this sequence. Table 14 is a list of the page-4 registers, excepting the previously described
register 0.
Table 14. Page-4 Registers
REGISTER
RESET VALUE
REGISTER NAME
NUMBER
1
XXXX XXXX
Reserved. Do not write to this register.
Coefficient N0(15:8) for AGC LPF (first-order IIR) used as averager to detect level or coefficient
2
0000 0001
C1(15:8) of ADC miniDSP
Coefficient N0(7:0) for AGC LPF (first-order IIR) used as averager to detect level or coefficient
3
0001 0111
C1(7:0) of ADC miniDSP
Coefficient N1(15:8) for AGC LPF (first-order IIR) used as averager to detect level or coefficient
4
0000 0001
C2(15:8) of ADC miniDSP
Coefficient N1(7:0) for AGC LPF (first-order IIR) used as averager to detect level or coefficient
5
0001 0111
C2(7:0) of ADC miniDSP
Coefficient D1(15:8) for AGC LPF (first-order IIR) used as averager to detect level or coefficient
6
0111 1101
C3(15:8) of ADC miniDSP
Coefficient D1(7:0) for AGC LPF (first-order IIR) used as averager to detect level or coefficient
7
1101 0011
C3(7:0) of ADC miniDSP
Coefficient N0(15:8) for left ADC programmable first-order IIR or coefficient C4(15:8) of ADC
8
0111 1111
miniDSP
9
1111 1111
Coefficient N0(7:0) for left ADC programmable first-order IIR or coefficient C4(7:0) of ADC miniDSP
Coefficient N1(15:8) for left ADC programmable first-order IIR or coefficient C5(15:8) of ADC
10
0000 0000
miniDSP
11
0000 0000
Coefficient N1(7:0) for left ADC programmable first-order IIR or coefficient C5(7:0) of ADC miniDSP
Coefficient D1(15:8) for left ADC programmable first-order IIR or coefficient C6(15:8) of ADC
12
0000 0000
miniDSP
13
0000 0000
Coefficient D1(7:0) for left ADC programmable first-order IIR or coefficient C6(7:0) of ADC miniDSP
Coefficient N0(15:8) for left ADC biquad A or coefficient FIR0(15:8) for ADC FIR filter or coefficient
14
0111 1111
C7(15:8) of ADC miniDSP
Coefficient N0(7:0) for left ADC biquad A or coefficient FIR0(7:0) for ADC FIR filter or coefficient
15
1111 1111
C7(7:0) of ADC miniDSP
Coefficient N1(15:8) for left ADC biquad A or coefficient FIR1(15:8) for ADC FIR filter or coefficient
16
0000 0000
C8(15:8) of ADC miniDSP
Coefficient N1(7:0) for left ADC biquad A or coefficient FIR1(7:0) for ADC FIR filter or coefficient
17
0000 0000
C8(7:0) of ADC miniDSP
Copyright
2008–2011, Texas Instruments Incorporated
65
