SLAS659 – NOVEMBER 2009
www.ti.com
Table 6-10. Page-12 Registers (continued)
REGISTER
RESET VALUE
REGISTER NAME
NUMBER
Coefficient N1(15:8) for left DAC-programmable biquad B or Coefficient C7(15:8) of DAC
14
0000 0000
miniDSP (DAC Buffer B)
Coefficient N1(7:0) for left DAC-programmable biquad B or Coefficient C7(7:0) of DAC
15
0000 0000
miniDSP (DAC Buffer B)
Coefficient N2(15:8) for left DAC-programmable biquad B or Coefficient C8(15:8) of DAC
16
0000 0000
miniDSP (DAC Buffer B)
Coefficient N2(7:0) for left DAC-programmable biquad B or Coefficient C8(7:0) of DAC
17
0000 0000
miniDSP (DAC Buffer B)
Coefficient D1(15:8) for left DAC-programmable biquad B or Coefficient C9(15:8) of DAC
18
0000 0000
miniDSP (DAC Buffer B)
Coefficient D1(7:0) for left DAC-programmable biquad B or Coefficient C9(7:0) of DAC
19
0000 0000
miniDSP (DAC Buffer B)
Coefficient D2(15:8) for left DAC-programmable biquad B or Coefficient C10(15:8) of DAC
20
0000 0000
miniDSP (DAC Buffer B)
Coefficient D2(7:0) for left DAC-programmable biquad B or Coefficient C10(7:0) of DAC
21
0000 0000
miniDSP (DAC Buffer B)
Coefficient NO(15:8) for left DAC-programmable biquad C or Coefficient C11(15:8) of DAC
22
0111 1111
miniDSP (DAC Buffer B)
Coefficient NO(7:0) for left DAC-programmable biquad C or Coefficient C11(7:0) of DAC
23
1111 1111
miniDSP (DAC Buffer B)
Coefficient N1(15:8) for left DAC-programmable biquad C or Coefficient C12(15:8) of DAC
24
0000 0000
miniDSP (DAC Buffer B)
Coefficient N1(7:0) for left DAC-programmable biquad C or Coefficient C12(7:0) of DAC
25
0000 0000
miniDSP (DAC Buffer B)
Coefficient N2(15:8) for left DAC-programmable biquad C or Coefficient C13(15:8) of DAC
26
0000 0000
miniDSP (DAC Buffer B)
Coefficient N2(7:0) for left DAC-programmable biquad C or Coefficient C13(7:0) of DAC
27
0000 0000
miniDSP (DAC Buffer B)
Coefficient D1(15:8) for left DAC-programmable biquad C or Coefficient C14(15:8) of DAC
28
0000 0000
miniDSP (DAC Buffer B)
Coefficient D1(7:0) for left DAC-programmable biquad C or Coefficient C14(7:0) of DAC
29
0000 0000
miniDSP (DAC Buffer B)
Coefficient D2(15:8) for left DAC-programmable biquad C or Coefficient C15(15:8) of DAC
30
0000 0000
miniDSP (DAC Buffer B)
Coefficient D2(7:0) for left DAC-programmable biquad C or Coefficient C15(7:0) of DAC
31
0000 0000
miniDSP (DAC Buffer B)
Coefficient NO(15:8) for left DAC-programmable biquad D or Coefficient C16(15:8) of DAC
32
0111 1111
miniDSP (DAC Buffer B)
Coefficient NO(7:0) for left DAC-programmable biquad D or Coefficient C16(7:0) of DAC
33
1111 1111
miniDSP (DAC Buffer B)
Coefficient N1(15:8) for left DAC-programmable biquad D or Coefficient C17(15:8) of DAC
34
0000 0000
miniDSP (DAC Buffer B)
Coefficient N1(7:0) for left DAC-programmable biquad D or Coefficient C17(7:0) of DAC
35
0000 0000
miniDSP (DAC Buffer B)
Coefficient N2(15:8) for left DAC-programmable biquad D or Coefficient C18(15:8) of DAC
36
0000 0000
miniDSP (DAC Buffer B)
Coefficient N2(7:0) for left DAC-programmable biquad D or Coefficient C18(7:0) of DAC
37
0000 0000
miniDSP (DAC Buffer B)
Coefficient D1(15:8) for left DAC-programmable biquad D or Coefficient C19(15:8) of DAC
38
0000 0000
miniDSP (DAC Buffer B)
Coefficient D1(7:0) for left DAC-programmable biquad D or Coefficient C19(7:0) of DAC
39
0000 0000
miniDSP (DAC Buffer B)
Coefficient D2(15:8) for left DAC-programmable biquad D or Coefficient C20(15:8) of DAC
40
0000 0000
miniDSP (DAC Buffer B)
88
REGISTER MAP
Copyright 2009, Texas Instruments Incorporated
Product Folder Link(s): TLV320DAC3120
