REV. 0
AD9873
–7–
ABSOLUTE MAXIMUM RATINGS
*
Power Supply (VAS, VDS) . . . . . . . . . . . . . . . . . . . . . . 3.9 V
Digital Output Current . . . . . . . . . . . . . . . . . . . . . . . . . 5 mA
Digital Inputs . . . . . . . . . . . . . . . –0.3 V to DRVDD + 0.3 V
Analog Inputs . . . . . . . . . . . . . –0.3 V to AVDD (IQ) +0.3 V
Operating Temperature . . . . . . . . . . . . . . . . . . . . 0 C to 70 C
Maximum Junction Temperature . . . . . . . . . . . . . . . . 150 C
Storage Temperature . . . . . . . . . . . . . . . . . . –65 C to +150 C
Lead Temperature (Soldering 10 sec) . . . . . . . . . . . . . 300 C
*
Absolute maximum ratings are limiting values, to be applied individually, and
beyond which the serviceability of the circuit may be impaired. Functional
operability under any of these conditions is not necessarily implied. Exposure of
absolute maximum rating conditions for extended periods of time may affect
device reliability.
EXPLANATION OF TEST LEVELS
I
– 100% production tested.
II
– Devices are 100% production tested at 25 C and guaran-
teed by design and characterization testing for commercial
operating temperature range (0 C to 70 C).
III
– Parameter is guaranteed by design and/or characteriz-
ation testing.
IV
– Parameter is a typical value only.
N/A – Test level definition is not applicable.
THERMAL CHARACTERISTICS
Thermal Resistance
100-Lead MQFP
JA
= 40.5 C/W
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although
the AD9873 features proprietary ESD protection circuitry, permanent damage may occur on
devices subjected to high-energy electrostatic discharges. Therefore, proper ESD precautions are
recommended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
ORDERING GUIDE
Temperature
Range
Package
Description
Package
Option
Model
AD9873JS
AD9873-EB
0 C to 70 C
Metric Quad Flatpack (MQFP)
Evaluation Board
S-100C
