TFP420
PanelBus
DIGITAL TRANSMITTER
SLDS123A – MARCH 2000 – REVISED JUNE 2000
5
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
Terminal Functions (Continued)
TERMINAL
NAME
POWER
RAIL
NO.
I/O
DESCRIPTION
Power and Ground
AVCC
3.3 V
37, 47
P
Analog power
AVSS
0.0 V
42
G
Analog ground
DVCC
3.3 V
12
P
Digital power
DVDD
1.8 V
1, 55
P
Digital power
DVDDQ
1.1 V–1.8 V
8
P
Digital power
DVSS
0.0 V
6, 16,
48, 58
G
Digital ground
PVDD
1.8 V
35
P
Power for PLLs
PVSS
0.0 V
36
G
Ground for PLLs
TVDD
1.8 V
23, 29
P
Analog power for the DVI output drivers
TVSS
0.0 V
20, 26,
32
G
Analog ground for the DVI output drivers
absolute maximum ratings over operating free-air temperature (unless otherwise noted)
External T.M.D.S. termination resistance, RLtmds
0
to open circuit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
External TFADJ resistor
1 k
to open circuit
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating free-air temperature range, TA
0
°C to 70°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range, Tstg
–65
°C to 150°C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum total power dissipation, PD
2 W
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
recommended operating conditions (ALL DATA PRELIMINARY)
MIN
NOM
MAX
UNIT
Digital supply voltage, DVDD
1.7
1.8
1.9
V
Digital supply voltage, DVDDQ
1.0
1.8
1.9
V
Analog supply voltage, AVCC
3.13
3.3
3.47
V
Analog supply voltage, TVDD
1.7
1.8
1.9
V
Analog supply voltage, PVDD
1.7
1.8
1.9
V
Digital low-level input voltage, DVDD VIL (scalable with V(REF)
V(REF)–100 mv
V
Digital low-level input voltage, DVDD VIH (scalable with V(REF)
V(REF)+100 mv
V
Digital low-level input voltage, DVCC VIL
0.8
V
Digital low-level input voltage, DVCC VIH
V
Digital supply current, DVDD
80
Digital supply current, DVDDQ
0
DVI 1280x1024 resolution 60 Hz refresh rate
Analog supply current, TVDD
120
mA
Analog supply current, AVCC
6
Analog supply voltage, PVDD
100
Reference voltage, V(REF)
0.52
0.9
0.95
V
External T.M.D.S. termination resistor
45
50
55
External TFADJ resistor
1.4
2
2.6
k
Operating free-air temperature, TA
0
70
°C
