TFP420
PanelBus
DIGITAL TRANSMITTER
SLDS123A – MARCH 2000 – REVISED JUNE 2000
17
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
register description (continued)
GP_CTRL
Subaddress = 41
Default = 0x80
7
6
5
4
3
2
1
0
GIO1_EN
Reserved
GP1_IN
GP0_IN
GP1_OE
GP0_OE
GP1_OUT
GP0_OUT
GP0_OUT General-purpose output bit. The state of this bit shows on GPIO0 terminal if GP0_OE is set to 1. Otherwise,
GPIO0 terminal goes to a high impedance state.
0(*)
GPIO0 terminal outputs LOW
1
GPIO0 terminal outputs HIGH
GP1_OUT General-purpose output bit. The state of this bit shows on GPIO1 terminal if GP1_OE is set to 1. Otherwise,
GPIO1 terminal goes to a high impedance state.
0(*)
GPIO1 terminal outputs LOW
1
GPIO1 terminal outputs HIGH
GP0_OE General-purpose bit output enable.
0(*)
GPIO0 output goes to a high impedance state.
1
GPIO0 output is enabled
GP1_OE General-purpose bit output enable.
0(*)
GPIO1 output goes to a high impedance state.
1
GPIO1 output is enabled
GP0_IN
General-purpose input bit. This bit shows the state of GPIO0 terminal.
0(*)
GPIO0 terminal is LOW
1
GPIO0 terminal is HIGH
GP0_IN
General-purpose input bit. This bit shows the state of GPIO1 terminal.
0(*)
GPIO1 terminal is LOW
1
GPIO1 terminal is HIGH
GIO1_EN .GPIO1 terminal enable
0(*)
HC/CS/GPIO1 outputs Horizontal or composite sync
1
HC/CS/GPIO1 is used as the second general-purpose I/O terminal.
GIO1_EN
GP1_OUT
GP1_OE
HS_COM
HSEN
VSEN
Terminal 45
0
X
0
X
LOW
0
X
1
0
LOW
0
X
1
0
1
VS
0
X
1
0
HS
0
X
1
CS
1
0
X
3-state
1
0
1
X
LOW
1
0
X
3-state
1
X
HIGH
