參數資料
型號： TLV320AIC36IZQE
廠商： TEXAS INSTRUMENTS INC
元件分類： 消費家電
英文描述： SPECIALTY CONSUMER CIRCUIT, PBGA80
封裝： 5 X 5 MM, GREEN, PLASTIC, VFBGA-80
文件頁數： 15/165頁
文件大小： 1895K
代理商： TLV320AIC36IZQE
www.ti.com
SBAS387A – MAY 2009 – REVISED JUNE 2010
6.2.98 Page 0 / Register 101:
Right Channel AGC Control Register 8
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
0000 0000
Right Channel AGC Gain Flag
1111 0100: Right Channel AGC Gain = -12.0 dB
1111 0101: Right Channel AGC Gain = -11.5 dB
1111 0110: Right Channel AGC Gain = -11.0 dB
…
0000 0000: Right Channel AGC Gain = 0.0 dB
…
0111 0010: Right Channel AGC Gain = 57.0 dB
0111 0011: Right Channel AGC Gain = 57.5 dB
0111 0100: Right Channel AGC Gain = 58.0 dB
6.2.99 Page 0 / Register 102:
DC Measurement Register 1
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
R/W
0
0: DC Measurement Mode disabled for Left ADC Channel
1: DC Measurement Mode enabled for Left ADC Channel
D6
R/W
0
0: DC Measurement Mode disabled for Right ADC Channel
1: DC Measurement Mode enabled for Right ADC Channel
D5
R/W
0
0: DC Measurement is done using First-Order moving average filter with averaging of 2^D
1: DC Measurement is done with 1sr order Low-pass IIR filter with coefficients as a function of D
D4–D0
R/W
0 0000
DC Measurement D setting
0 0000: Reserved. Do not use
0 0001: DC Measurement D parameter = 1
0 0010: DC Measurement D parameter = 2
..
1 0011: DC Measurement D parameter = 19
1 0100: DC Measurement D parameter = 20
1 0101-1 1111: Reserved. Do not use
6.2.100 Page 0 / Register 103:
DC Measurement Register 2
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D6
R
00
Reserved. Write only default values
D5
R/W
0
0: For IIR based DC measurement, measurement value is the instantaneous output of IIR filter
1: For IIR based DC measurement, the measurement value is updated before periodic clearing of
IIR filter
D4–D0
R/W
0 0000
IIR based DC Measurement, averaging time setting
0 0000: Infinite average is used
0 0001: Averaging time is 2^1 ADC Modulator clocks
0 0010: Averaging time is 2^2 ADC Modulator clocks
…
1 0011: Averaging time is 2^19 ADC Modulator clocks
1 0100: Averaging time is 2^20 ADC Modulator clocks
1 0101-1 1111: Reserved. Do not use
6.2.101 Page 0 / Register 104:
Left Channel DC Measurement Output Register 1
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
0000 0000
Left Channel DC Measurement Output (23:16)
Copyright 2009–2010, Texas Instruments Incorporated
REGISTER MAP
111
Product Folder Link(s): TLV320AIC36
