I
Z684 PCI Bus Controller
I
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
8
OKI SEMICONDUCTOR
OPERRB
Output
LOW
Parity Error
errors during all PCI transactions except special cycles. The OPERRB signal is the output
signal for the PCI PERR# pin.
. This is the parity error reporting signal. The OPERRB signal reports data parity
OSERRB
Output
LOW
System Error
cycle data parity errors. The OSERRB pin is the output signal for the PCI SERR# pin.
. This is the system error signal. The OSERRB signal reports address and special
OAD[31:0]
Output
–
AD Address and Data Bus
. These are PCI multiplexed address and data bus outputs.
OCBEB[3:0]
Output
–
Command and Byte Enable Bus
outputs with the PCI command definitions shown below.
. These are PCI multiplexed command and byte enable bus
PCI Interface Signals
(Continued)
Signal
Type
Assertion
Description
OCBEB[3:0]
Command Type
0000
Interrupt Acknowledge
0001
Special Cycle
0010
I/O Read
0011
I/O Write
0100
Reserved
0101
Reserved
0110
Memory Read
0111
Memory Write
OCBEB[3:0]
Command Type
1000
Reserved
1001
Reserved
1010
Configuration Read
1011
Configuration Write
1100
Memory Read Multiple
1101
Dual Access Cycle
1110
Memory Read Line
1111
Memory Write and Invalidate
