ADM1060 LOGIC
ADM1060
–
23
–
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
75
33
P8G PIIM K
00h
Polarity Sense and Ignore Mask bits for all 4 GPI
’
s when
used as inputs to the B function of PLB8
76
34
P8W D IC F G
00h
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB8
77
35
PS8E N
00h
Enable bits for A and B functions of PLB8, polarity bit
for PL B8 output
78
28
P8PL BPOL B
00h
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB8
79
29
P8PL BIM K B
00h
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB8
7A
30
P8SF D POL B
00h
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP
’
s) to
the B function of PLB8
7B
31
P8SF D IM K B
00h
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP
’
s) to
the B function of PLB8
80
28
P9PL BPOL A
00h
Polarity Sense for all 8 other PLB outputs when used as
inputs to the A function of PLB9
81
29
P9PL BIM K A
00h
Ignore Mask for all 8 other PLB outputs when used as
inputs to the A function of PLB9
82
30
P9SF D POL A
00h
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP
’
s) to
the A function of PLB9
83
31
P9SF D IM K A
00h
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP
’
s) to
the A function of PLB9
84
32
P9G PIPOL
00h
Polarity Sense and Ignore Mask bits for all 4 GPI
’
s when
used as inputs to the A function of PLB9
85
33
P9G PIIM K
00h
Polarity Sense and Ignore Mask bits for all 4 GPI
’
s when
used as inputs to the B function of PLB9
86
34
P9W D IC F G
00h
Polarity Sense and Ignore Mask bits for the pulsed and
latched outputs of the watchdog detector when used as
inputs to both A and B functions of PLB9
87
35
PS9E N
00h
Enable bits for A and B functions of PLB9, polarity bit
for PL B9 output
88
28
P9PL BPOL B
00h
Polarity Sense for all 8 other PLB outputs when used as
inputs to the B function of PLB9
89
29
P9PL BIM K B
00h
Ignore Mask for all 8 other PLB outputs when used as
inputs to the B function of PLB9
8A
30
P9SF D POL B
00h
Polarity Sense for all 7 SFD inputs (VH, 2 VB, 4 VP
’
s) to
the B function of PLB9
8B
31
P9SF D IM K B
00h
Ignore Mask for all 7 SFD inputs (VH, 2 VB, 4 VP
’
s) to
the B function of PLB9
T ABL E 27. L IST OF RE GIST E RS F OR T HE PROGRAMMABL E L OGIC BL OC K ARRAY (PL BA) (C ontd.)
Hex
T able
Name
D efault
Address
Power On Value
Description
