ADM1060
ADM1060 OUTPUTS
–
30
–
REV. PrJ 11/02
PRELIMINARY TECHNICAL DATA
T A BL E 39. R E GIST E R 0D H ,1D H ,2D H ,3D H ,4D H ,5D H ,6D H ,7D H ,8D H PnPD OC F G (POWE R - ON D E F A UL T 00H )
Bit
Name
R/W
Description
7
Reserved
N/A
Cannot be used
6-4
C F G 6-C F G 4
R /W
Control the logical state of the PDO. T hese three bits deter
mine what effect, if any, the logical input to the PDO has on its output
CFG6
0
0
0
0
1
CFG5
0
0
1
1
X
CFG4
0
1
0
1
X
PD O
0
PL B_OU T
0
1
M C L K
State
Disabled, with weak pull-down
Enabled, follows PL B L ogic Output
Enable SMBus Data, Drive Low
Enable SMBus Data, Drive High
Enable MCLK out onto pin
3-0
C F G 3-C F G 0
R /W
CFG3
CFG2
CFG1
CFG0
Pull-Up
Supply
Pull-Up
Strength
0
0
0
0
0
0
1
1
1
1
1
1
0
0
1
1
1
1
0
0
0
0
1
1
0
1
0
0
1
1
0
0
1
1
1
1
X
X
0
1
0
1
0
1
0
1
0
1
none
V C P
V P1
V P1
V P2
V P2
V P3
V P3
V P4
V P4
V D D
V D D
N/A
(1/fC )
L ow
H igh
L ow
H igh
L ow
H igh
L ow
H igh
L ow
H igh
T ABLE 38. LIST OF RE GIST E RS FOR T HE PROGRAMMABLE DRIVE R OUT PUT S
Hex
T able
Name
Address
D efault
Description
Power On Value
0D
39
P1PD OC F G
00h
Selects the format of the PDO1 output (open drain, open
drain with internal pull-up, charge pumped etc.)
1D
39
P2PD OC F G
00h
Selects the format of the PDO2 output (open drain, open
drain with internal pull-up, charge pumped etc.)
2D
39
P3PD OC F G
00h
Selects the format of the PDO3 output (open drain, open
drain with internal pull-up, charge pumped etc.)
3D
39
P4PD OC F G
00h
Selects the format of the PDO4 output (open drain, open
drain with internal pull-up, charge pumped etc.)
4D
39
P5PD OC F G
00h
Selects the format of the PDO5 output (open drain, open
drain with internal pull-up etc.).
Note:
C harge Pumped
output is not available on this driver
5D
39
P6PD OC F G
00h
Selects the format of the PDO6 output (open drain, open
drain with internal pull-up etc.).
Note:
C harge Pumped
output is not available on this driver
6D
39
P7PD OC F G
00h
Selects the format of the PDO7 output (open drain, open
drain with internal pull-up etc.).
Note: C harge Pumped
output is not available on this driver
7D
39
P8PD OC F G
00h
Selects the format of the PDO8 output (open drain, open
drain with internal pull-up etc.).
Note: C harge Pumped
output is not available on this driver
8D
39
P9PD OC F G
00h
Selects the format of the PDO9 output (open drain, open
drain with internal pull-up etc.).
Note: C harge Pumped
output is not available on this driver
