TFP6422, TFP6424
PanelBus
DIGITAL TRANSMITTER/VIDEO ENCODER COMBO
SLDS118 – MARCH 2000
46
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
PLL_STATUS
Subaddress = 4F
Read Only
7
6
5
4
3
2
1
0
STATUS_HI[2:0]
STATUS_LO[2:0]
Low-range PLL lock status
001
The low-range PLL is not locked due to the selected frequency range being
too low. PLL_LO[1:0] needs to be adjusted to move to a higher frequency
range.
110
The low-range PLL is not locked due to the selected frequency range being too
high. PLL_LO[1:0] needs to be adjusted to move to a lower frequency range.
Other Low-range PLL is locked. Do not adjust PLL_LO[1:0]
STATUS_HI[2:0]
High-range PLL lock status
001
The high-range PLL is not locked due to the selected frequency range being
too low. PLL_HI[1:0] needs to be adjusted to move to a higher frequency range.
110
The high-range PLL is not locked due to the selected frequency range being
too high. PLL_HI[1:0] needs to be adjusted to move to a lower frequency
range.
Other Low-range PLL is locked. Do not adjust PLL_HI[1:0]
FIFO_DLY
Subaddress = 50
Default = 0xBC
7
6
5
4
3
2
1
0
FIFO_DLY[7:0]
Subaddress = 51
Default = 0x02
7
6
5
4
3
2
1
0
FIFO_DLY[15:8]
FIFO_DLY[15:0]
FIFO delay control
1
PRODUCT
PREVIEW
