TFP6422, TFP6424
PanelBus
DIGITAL TRANSMITTER/VIDEO ENCODER COMBO
SLDS118 – MARCH 2000
56
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
flal
Subaddress = 7d
Default = 0x22
7
6
5
4
3
2
1
0
LAL[8]
FAL[8]
FLEM[9:8]
Overflow bits from FLEN, FAL and LAL Registers.
LAL[8]
These bits define the last active line of a field. The LSB is located in register LAL.
FAL[8]
These bits define the first active line of a field. The LSB is located in register FAL.
FLEN[9:8]
These bits define the number of half_lines in each field. The lower 8 bits of this register are located in
FLEN register.
SYN_CTRL1
Subaddress = 7E
Default = 0x00 or 0x80
7
6
5
4
3
2
1
0
FREE
ESAV
IGNP
NBLNKS
VBLKM[1:0]
HBLKM[1:0]
FREE
Free running
0(*)
Free running disabled.
1(*)
Free running enabled. HSYNC and VSYNC are ignored.
Reset to 0 if the CBAR pin is high upon reset otherwise reset to 1.
ESAV
Enable to detect F and V bits only on EAV in CCIR656 input mode
0(*)
Detection of F and V bits on both EAV and SAV
1
Detection of F and V bits only on EAV.
IGNP
Ignore protection bits in CCIR656 input mode
0(*)
Protection bits are not ignored.
1
Protection bits are ignored
NBLNKS
Blank shaping
0(*)
Blank shaping enabled
1
Blank shaping disabled
VBLKM[1:0] Vertical blanking mode
00(*)
Internal default blanking
01
Internal default blanking AND internal programmable blanking defined by FAL and LAL
10
Internal blanking and external blanking defined by BLANK
11
Internal blanking AND internal programmable blanking defined by FAL
and LAL AND external blanking defined by BLANK
HBLKM[1:0] Horizontal blanking mode
00(*)
Internal default blanking
01
Internal programmable blanking defined by SAVID and EAVID
10
External blanking defined by BLANK
11
Internal programmable blanking defined by SAVID and EAVID
AND external blanking defined by BLANK
BORDER_Y
Subaddress = 7F
Default = 0x10
7
6
5
4
3
2
1
0
BORDER_Y[7:0]
BORDER_Y[7:0] Y component of the border color
PRODUCT
