TFP6422, TFP6424
PanelBus
DIGITAL TRANSMITTER/VIDEO ENCODER COMBO
SLDS118 – MARCH 2000
53
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
PIXEL TYPE
SUBCARRIER FREQUENCY
(Fsc)
CLOCK
(Fclock)
S_Carr
(Dec)
S_Carr
(Hex)
Rectangular
3.5795452 MHz
27 MHz
569408543(*)
21F07C1F
Rectangular
4.43361875 MHz
27 MHz
705268427
2A098ACB
Rectangular
3.58205625 MHz
27 MHz
569807942
21F69446
Rectangular
3.5756083125 MHz
27 MHz
568782819
21E6EFE3
Square
3.579545 MHz
24.5454 MHz
626349397
25555555
Square
4.43361875 MHz
29.50 MHz
645499916
26798C0C
Square
3.58205625 MHz
29.50 MHz
521519134
1F15C01E
Square
3.5756083125 MHz
24.5454 MHz
625661101
254AD4AD
LINE21_O0
Subaddress = 67
Default = 0x00
7
6
5
4
3
2
1
0
L21O[7:0]
The least significant byte of the closed caption data in the odd field.
LINE21_O1
Subaddress = 68
Default = 0x00
7
6
5
4
3
2
1
0
L21O[15:8]
The most significant byte of the closed caption data in the odd field.
LINE21_E0
Subaddress = 69
Default = 0x00
7
6
5
4
3
2
1
0
L21E[15:8]
L21E[7:0]
The least significant byte of the extended service data in the even field.
LINE21_E1
Subaddress = 6A
Default = 0x00
7
6
5
4
3
2
1
0
L21E[15:8]
The least significant byte of the extended service data in the even field.
LN_SEL
Subaddress = 6B
Default = 0x0B
7
6
5
4
3
2
1
0
SLINE[4:0]
Selects the line where closed caption or extended service data are encoded.
L21
Subaddress = 6D
Default = 0x00
7
6
5
4
3
2
1
0
L21ENA
L21ENB
L21ENA
This bit controls the closed caption encoding. See following register for programming information.
L21ENB
This bit controls the closed caption encoding. See following register for programming information.
PRODUCT
PREVIEW
