REV. 0
AD9860/AD9862
–5–
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although the
AD9860/AD9862 features proprietary ESD protection circuitry, permanent damage may occur on
devices subjected to high energy electrostatic discharges. Therefore, proper ESD precautions are
recommended to avoid performance degradation or loss of functionality.
ABSOLUTE MAXIMUM RATINGS
1
Power Supply (V
AS
, V
DS
) . . . . . . . . . . . . . . . . . . . . . . . . . 3.9 V
Digital Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . 5 mA
Digital Inputs . . . . . . . . . . . . . . . .
–
0.3 V to DRVDD + 0.3 V
Analog Inputs . . . . . . . . . . . . . .
–
0.3 V to AVDD (IQ) + 0.3 V
Operating Temperature
2
. . . . . . . . . . . . . . . . .
–
40 C to +70 C
Maximum Junction Temperature . . . . . . . . . . . . . . . . . 150 C
Storage Temperature . . . . . . . . . . . . . . . . . . .
–
65 C to +150 C
Lead Temperature (Soldering 10 sec) . . . . . . . . . . . . . . 300 C
NOTES
1
Absolute maximum ratings are limiting values, to be applied individually, and
beyond which the serviceability of the circuit may be impaired. Functional operability
under any of these conditions is not necessarily implied. Exposure to absolute
maximum rating conditions for extended periods of time may affect device
reliability.
2
The AD9860/AD9862 have been characterized to operate over the industrial
temperature range (
–
40 C to +85 C) when operated in Half Duplex Mode.
EXPLANATION OF TEST LEVELS
I.
Devices are 100% production tested at 25
o
C and guaranteed
by design and characterization testing for the extended
industrial temperature range (
–
40
o
C to +70
o
C).
II.
Parameter is guaranteed by design and/or characterization
testing.
III. Parameter is a typical value only.
NA. Test level definition is not applicable.
THERMAL CHARACTERISTICS
Thermal Resistance
128-Lead LQFP
JA
= 29
o
C/W
ORDERING GUIDE
Package Description
Model
Temperature Range
Package Option
AD9860BST
AD9862BST
AD9860PCB
AD9862PCB
–
40
∞
C to +70
∞
C
*
–
40
∞
C to +70
∞
C
*
128-Lead Low Profile Plastic Quad Flatpack (LQFP)
128-Lead Low Profile Plastic Quad Flatpack (LQFP)
Evaluation Board with AD9860
Evaluation Board with AD9862
ST-128B
ST-128B
*
The AD9860/AD9862 have been characterized to operate over the industrial temperature range (
–
40 C to +85 C) when operated in Half Duplex Mode.
