1.
General description
The UJA1065 System Basis Chip (SBC) replaces basic discrete components which are
common in every Electronic Control Unit (ECU) with a Controller Area Network (CAN) and
a Local Interconnect Network (LIN) interface. The SBC supports all networking
applications which control various power and sensor peripherals by using high-speed
CAN as the main network interface and LIN as a local sub-bus. The SBC contains the
following integrated devices:
High-speed CAN transceiver, inter-operable and downwards compatible with CAN
transceiver TJA1041 and TJA1041A, and compatible with the ISO11898-2 standard
and the ISO11898-5 standard (in preparation)
LIN transceiver compliant with LIN 2.0 and SAE J2602, and compatible with LIN 1.3
Advanced independant watchdog
Dedicated voltage regulators for microcontroller and CAN transceiver
Serial peripheral interface (full duplex)
Local wake-up input port
Inhibit / limp home output port
In addition to the advantages of integrating these common ECU functions in a single
package, the SBC offers an intelligent combination of system-specific functions such as:
Advanced low power concept
Safe and controlled system start-up behavior
Advanced fail-safe system behavior that prevents any conceivable deadlock
Detailed status reporting on system and sub-system levels
The UJA1065 is designed to be used in combination with a microcontroller with a CAN
controller. The SBC ensures that the microcontroller is always started up in a defined
manner. In failure situations the SBC will maintain the microcontroller function for as long
as possible, to provide full monitoring and software driven fall-back operation.
The UJA1065 is designed for 14 V single power supply architectures and for 14 V and
42 V dual power supply architectures.
UJA1065
High-speed CAN/LIN fail-safe system basis chip
Rev. 01 — 10 August 2005
Objective data sheet
