SLAS659 – NOVEMBER 2009
www.ti.com
Page 0 / Register 44: Interrupt Flags—DAC
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7(1)
R
0
0: No short circuit is detected at HPOUT / class-D driver.
1: Short circuit is detected at HPOUT / class-D driver.
D6(1)
R
0
Reserved
D5(1)
R
X
0: No headset button pressed
1: Headset button pressed
D4(1)
R
X
0: No headset insertion/removal is detected.
1: Headset insertion/removal is detected.
D3(1)
R
0
0: DAC signal power is les than or equal to the signal threshold of DRC.
1: DAC signal power is above the signal threshold of DRC.
D2(1)
R
0
Reserved.
D1(1)
R
0
DAC miniDSP Engine Standard Interrupt-Port Output
0: Read a 0 from Standard Interrupt-Port
1: Read a 1 from Standard Interrupt-Port
D0(1)
R
0
DAC miniDSP Engine Auxilliary Interrupt-Port Output
0: Read a 0 from Auxilliary Interrupt-Port
1: Read a 1 from Auxilliary Interrupt-Port
(1)
Sticky flag bIts. These are read-only bits. They are automatically cleared once they are read and are set only if the source trigger occurs
again.
Page 0 / Register 45: Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R/W
XXXX XXXX
Reserved. Write only the reset value to these bits.
Page 0 / Register 46: Interrupt Flags – DAC
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7
R
0
0: No short circuit detected at HPOUT / class-D driver
1: Short circuit detected at HPOUT / class-D driver
D6
R
0
Reserved
D5
R
X
0: No headset button pressed
1: Headset button pressed
D4
R
X
0: Headset removal detected
1: Headset insertion detected
D3
R
0
0: DAC signal power is below signal threshold of DRC.
1: DAC signal power is above signal threshold of DRC.
D2
R
0
Reserved.
D1
R
0
DAC miniDSP Engine Standard Interrupt Port Output
0: Read a 0 from Standard Interrupt-Port
1: Raed a 1 from Standard Interrupt-Port
D0
R
0
DAC miniDSP Engine Auxiliary Interrupt Port Output
0: Read a 0 from Auxilliary Interrupt-Port
1: Read a 1 from Auxilliary Interrupt-Port
Page 0 / Register 47: Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R/W
XXXX XXXX
Reserved. Write only the reset value to these bits.
60
REGISTER MAP
Copyright 2009, Texas Instruments Incorporated
Product Folder Link(s): TLV320DAC3120
