www.ti.com
SLAS659 – NOVEMBER 2009
Table 6-6. Page-8 Registers (continued)
REGISTER
RESET VALUE
REGISTER NAME
NUMBER
Coefficient N2(15:8) for left DAC-programmable biquad F or Coefficient C28(15:8) of DAC
56
0000 0000
miniDSP (DAC Buffer A)
Coefficient N2(7:0) for left DAC-programmable biquad F or Coefficient C28(7:0) of DAC
57
0000 0000
miniDSP (DAC Buffer A)
Coefficient D1(15:8) for left DAC-programmable biquad F or Coefficient C29(15:8) of DAC
58
0000 0000
miniDSP (DAC Buffer A)
Coefficient D1(7:0) for left DAC-programmable biquad F or Coefficient C29(7:0) of DAC
59
0000 0000
miniDSP (DAC Buffer A)
Coefficient D2(15:8) for left DAC-programmable biquad F or Coefficient C30(15:8) of DAC
60
0000 0000
miniDSP (DAC Buffer A)
Coefficient D2(7:0) for left DAC-programmable biquad F or Coefficient C30(7:0) of DAC
61
0000 0000
miniDSP (DAC Buffer A)
62
0000 0000
Coefficient C31(15:8) of DAC miniDSP (DAC Buffer A)
63
0000 0000
Coefficient C31(7:0) of DAC miniDSP (DAC Buffer A)
Coefficient C32(15:8) of DAC miniDSP (DAC Buffer A)—also used for the 3D PGA for
64
0000 0000
PRB_P23, PRB_P24 and PRB_P25
Coefficient C32(7:0) of DAC miniDSP (DAC Buffer A)—also used for the 3D PGA for
65
0000 0000
PRB_P23, PRB_P24 and PRB_P25
Coefficient N0(15:8) for right DAC-programmable biquad A or Coefficient C33(15:8) of DAC
66
0111 1111
miniDSP (DAC Buffer A)
Coefficient N0(7:0) for right DAC-programmable biquad A or Coefficient C33(7:0) of DAC
67
1111 1111
miniDSP (DAC Buffer A)
Coefficient N1(15:8) for right DAC-programmable biquad A or Coefficient C34(15:8) of DAC
68
0000 0000
miniDSP (DAC Buffer A)
Coefficient N1(7:0) for right DAC-programmable biquad A or Coefficient C34(7:0) of DAC
69
0000 0000
miniDSP (DAC Buffer A)
Coefficient N2(15:8) for right DAC-programmable biquad A or Coefficient C35(15:8) of DAC
70
0000 0000
miniDSP (DAC Buffer A)
Coefficient N2(7:0) for right DAC-programmable biquad A or Coefficient C35(7:0) of DAC
71
0000 0000
miniDSP (DAC Buffer A)
Coefficient D1(15:8) for right DAC-programmable biquad A or Coefficient C36(15:8) of DAC
72
0000 0000
miniDSP (DAC Buffer A)
Coefficient D1(7:0) for right DAC-programmable biquad A or Coefficient C36(7:0) of DAC
73
0000 0000
miniDSP (DAC Buffer A)
Coefficient D2(15:8) for right DAC-programmable biquad A or Coefficient C37(15:8) of DAC
74
0000 0000
miniDSP (DAC Buffer A)
Coefficient D2(7:0) for right DAC-programmable biquad A or Coefficient C37(7:0) of DAC
75
0000 0000
miniDSP (DAC Buffer A)
Coefficient N0(15:8) for right DAC-programmable biquad B or Coefficient C38(15:8) of DAC
76
0111 1111
miniDSP (DAC Buffer A)
Coefficient N0(7:0) for right DAC-programmable biquad B or Coefficient C38(7:0) of DAC
77
1111 1111
miniDSP (DAC Buffer A)
Coefficient N1(15:8) for right DAC-programmable biquad B or Coefficient C39(15:8) of DAC
78
0000 0000
miniDSP (DAC Buffer A)
Coefficient N1(7:0) for right DAC-programmable biquad B or Coefficient C39(7:0) of DAC
79
0000 0000
miniDSP (DAC Buffer A)
Coefficient N2(15:8) for right DAC-programmable biquad B or Coefficient C40(15:8) of DAC
80
0000 0000
miniDSP (DAC Buffer A)
Coefficient N2(7:0) for right DAC-programmable biquad B or Coefficient C40(7:0) of DAC
81
0000 0000
miniDSP (DAC Buffer A)
Coefficient D1(15:8) for right DAC-programmable biquad B or Coefficient C41(15:8) of DAC
82
0000 0000
miniDSP (DAC Buffer A)
Coefficient D1(7:0) for right DAC-programmable biquad B or Coefficient C41(7:0) of DAC
83
0000 0000
miniDSP (DAC Buffer A)
Copyright 2009, Texas Instruments Incorporated
REGISTER MAP
75
Product Folder Link(s): TLV320DAC3120
