37
AMI Semiconductor - Rev. 2.0, Jun. 05
www.amis.com
FS6131-01/FS6131-01g Programmable Line Lock Clock Generator IC
Data Sheet
The output clock frequency is calculated as
MHz
0
.
12
800
kHz
15
=
=
CLK
f
For best performance, program the post divider (NPx) modulus to allow the VCO to operate at a nominal frequency that is at least 70MHz but less
than 230MHz. The VCO frequency (fVCO) can be calculated by
Px
CLK
VCO
N
f
=
Selecting the post divider modulus of NPx=6 is a reasonable solution, although there are a number of values that will work. Try to keep
5000
<
Px
F
N
to avoid divider values from becoming too large. The settings place the VCO frequency at about 72MHz.
Calculate the ideal charge pump current (Ipump) as
VCO
lf
Px
F
HSYNC
pump
A
C
R
N
kHz
f
I
2
15
=
where Rlf is the external loop filter series resistor, Clf is the external loop filter series capacitor and AVCO is the VCO gain. The VCO gain is either
AVCO=125MHz/V if the high range is selected, or
AVCO=75MHz/V if the low range is selected.
See Table 15 for more information on the VCO range. With fhsync=15kHz, Clf=0.015
mF, Rlf=15kW, NF=800, NPx=6, and AVCO=125MHz/V, the charge
pump current is 24
mA. A 220pF cap across the entire loop filter is also helpful.
14.2 Example Programming
To generate 800 pixel clocks between HSYNC pulses occurring on the line reference signal every 15kHz, program the following (refer to Figure
27):
Clear the OSCTYPE bit to 0
Turn off the crystal oscillator via XLROM=7
Set the PFD inputs to select the REF and FBK pins via PDREF=1 and PDFBK=1
Set NP1=2, NP2=3 and NP3=1 for a combined post divider modulus of NPx=6 via POST1[1:0], POST2[1:0] and POST3[1:0].
Select the external loop filter via EXTLF=1
Set XLVTEN=0 and XLPDEN=1 to disable the VCXO fine tune and the crystal loop phase frequency detector
Set VCOSPD=1 to select the VCO low speed range
Set MLCP[1:0] to 3 to select the 32mA range
The output clock frequency fCLK is 12MHz, with an internal VCO frequency of 72MHz. Note that the crystal loop was unused in this application.
