www.ti.com
SLAS671 – FEBRUARY 2010
Page 0 / Register 39 (0x27): Overflow Flags
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7(1)
R
0
Left-Channel DAC Overflow Flag
0: Overflow has not occurred.
1: Overflow has occurred.
D6(1)
R
0
Right-Channel DAC Overflow Flag
0: Overflow has not occurred.
1: Overflow has occurred.
D5(1)
R
0
DAC Barrel Shifter Output Overflow Flag
0: Overflow has not occurred.
1: Overflow has occurred.
D4–D0
R
0 0000
Reserved
(1)
Sticky flag bits. These are read-only bits. They are automatically cleared once they are read and are set only if the source trigger occurs
again.
Page 0 / Register 40 (0x28) Through Page 0 / Register 43 (0x2B): Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
XXXX XXXX
Reserved. Do not use.
Page 0 / Register 44 (0x2C): DAC Interrupt Flags (Sticky Bits)
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7(1)
R
0
0: No short circuit is detected at HPL/left class-D driver.
1: Short circuit is detected at HPL/left class-D driver.
D6(1)
R
0
0: No short circuit is detected at HPR/right class-D driver.
1: Short circuit is detected at HPR/right class-D driver.
D5(1)
R
X
0: No headset button pressed
1: Headset button pressed
D4(1)
R
X
0: No headset insertion/removal is detected.
1: Headset insertion/removal is detected.
D3(1)
R
0
0: Left DAC signal power is
≤ the signal threshold of DRC.
1: Left DAC signal power is > the signal threshold of DRC.
D2(1)
R
0
0: Right DAC signal power is
≤ the signal threshold of DRC.
1: Right DAC signal power is > the signal threshold of DRC.
D1–D0
R
00
Reserved
(1)
Sticky flag bits. These are read-only bits. They are automatically cleared once they are read and are set only if the source trigger occurs
again.
Page 0 / Register 45 (0x2D): Reserved
READ/
RESET
BIT
DESCRIPTION
WRITE
VALUE
D7–D0
R
0000 0000
Reserved. Do not use.
Copyright 2010, Texas Instruments Incorporated
REGISTER MAP
67
Product Folder Link(s): TLV320DAC3100
