MPC750 RISC Microprocessor Technical Summary
17
The following sections summarize the features of the MPC750, distinguishing those that are defined by the
architecture from those that are unique to the MPC750 implementation.
The PowerPC architecture consists of the following layers, and adherence to the PowerPC architecture can
be described in terms of which of the following levels of the architecture is implemented:
PowerPC user instruction set architecture (UISA)—Defines the base user-level instruction set, user-
level registers, data types, floating-point exception model, memory models for a uniprocessor
environment, and programming model for a uniprocessor environment.
PowerPC virtual environment architecture (VEA)—Describes the memory model for a
multiprocessor environment, defines cache control instructions, and describes other aspects of
virtual environments. Implementations that conform to the VEA also adhere to the UISA, but may
not necessarily adhere to the OEA.
PowerPC operating environment architecture (OEA)—Defines the memory management model,
supervisor-level registers, synchronization requirements, and the exception model.
Implementations that conform to the OEA also adhere to the UISA and the VEA.
The PowerPC architecture allows a wide range of designs for such features as cache and system interface
implementations. The MPC750 implementations support the three levels of the architecture described
above. For more information about the PowerPC architecture, see
Programming Environments
.
PowerPC Microprocessor Family: The
Specific features of the MPC750 are listed in Section 1.1, “MPC750 Microprocessor Features.”
2.1 PowerPC Registers and Programming Model
The PowerPC architecture defines register-to-register operations for most computational instructions.
Source operands for these instructions are accessed from the registers or are provided as immediate values
embedded in the instruction opcode. The three-register instruction format allows specification of a target
register distinct from the two source operands. Load and store instructions transfer data between registers
and memory.
PowerPC processors have two levels of privilege—supervisor mode of operation (typically used by the
operating system) and user mode of operation (used by the application software). The programming models
incorporate 32 GPRs, 32 FPRs, special-purpose registers (SPRs), and several miscellaneous registers. Each
PowerPC microprocessor also has its own unique set of hardware implementation (HID) registers.
Having access to privileged instructions, registers, and other resources allows the operating system to
control the application environment (providing virtual memory and protecting operating-system and critical
machine resources). Instructions that control the state of the processor, the address translation mechanism,
and supervisor registers can be executed only when the processor is operating in supervisor mode.
Figure 5 shows all the MPC750 registers available at the user and supervisor level. The numbers to the right
of the SPRs indicate the number that is used in the syntax of the instruction operands to access the register.
