3.4 System Protection Block
System protection includes a bus monitor, a halt monitor, a spurious interrupt monitor, and a software
watchdog timer. These functions reduce the number of external components required for complete sys-
tem control.
Figure 9
shows the system protection block.
Figure 9 System Protection Block
3.4.1 System Protection Control Register
The system protection control register controls the software watchdog timer, bus monitor, and halt
monitor. This register can be written only once following power-on or reset, but can be read at any time.
SWE — Software Watchdog Enable
0 = Software watchdog disabled
1 = Software watchdog enabled
SYPCR —
System Protection Control Register
$YFFA21
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
NOT USED
SWE
SWP
SWT[1:0]
HME
BME
BMT
RESET:
1
MODCLK
0
0
0
0
0
0
SYS PROTECT BLOCK
MODULE CONFIGURATION
AND TEST
RESET STATUS
HALT MONITOR
BUS MONITOR
SPURIOUS INTERRUPT MONITOR
SOFTWARE WATCHDOG TIMER
PERIODIC INTERRUPT TIMER
2
9
PRESCALER
CLOCK
IRQ[7:1]
BERR
RESET REQUEST
RESET REQUEST
